GRAVIMETRIC DOSING SYSTEMS
PROMX 300
FEATURES:
- Up to 300 kg/h
- Max. 4 components
- Easy cleaning
- Integrated conveying
- Automatic adaptation to bulk density
- Emptying function
- including mounting frame
- Manual operation
DESCRIPTION:
Gravimetric batch dosing device for plastic granulate, additives and regrinds. Up to 4 components are successively dosed into the weighing hopper via dosing sliders and/or drum dosing devices. The device has an integrated conveying system.
TECHNICAL SPECIFICATIONS:
Design: Stainless steel
Dosing: Dosing slider / Drum dosing device
Batch size: max. 5kg
Material storage: D210 – 4,5 Liter
Weighing bin: 16 Liter
Mixing container: 20 Liter
Cotrol system: LCD 8-rows
Connection: 380-480 VAC / 50-60 Hz
Compressed air: 6 atm
PROMX 300 MOBIL
FEATURES:
- Complete machine supply in one system
- Including side channel blower 4,3 kW
- Including prefilter VF30
- Up to 300 kg/h
- Max. 4 components
- Easy cleaning
- Integrated conveying
- Automatic adaptation to bulk density
- Emptying function
- Manual operation
DESCRIPTION:
MOBILE, gravimetric batch dosing device for plastic granulate, additives and regrinds. Up to 4 components are successively dosed into the weighing hopper via dosing sliders and/or drum dosing devices. The device has an integrated conveying system.
TECHNICAL SPECIFICATIONS:
Design: Stainless steel
Dosing: Dosing slider / Drum dosing device
Batch size: max. 5kg
Material storage: D210 – 4,5 Liter
Weighing bin: 16 Liter
Mixing container: 20 Liter
Cotrol system: LCD 8-rows
Connection: 380-480 VAC / 50-60 Hz
Compressed air: 6 atm
PROMX 700
FEATURES:
- Up to 700 kg/h
- Max. 5 components
- Easy cleaning
- Integrated conveying
- Automatic adaptation to bulk density
- Emptying function
- including mounting frame
- Manual operation
DESCRIPTION:
Gravimetric batch dosing device for plastic granulate, additives and regrinds. Up to 5 components are successively dosed into the weighing hopper via dosing sliders. The device has an integrated conveying system.
TECHNICAL SPECIFICATIONS:
Design: Stainless steel
Dosing: Dosing slider
Batch size: max. 10kg
Material storage: D210 – 4,5 Liter, D300 – 20 Liter, D370 – 16 Liter
Weighing bin: 35 Liter
Mixing container: 60 Liter
Control system: LCD 8-rows
Connection: 380-480 VAC / 50-60 Hz
Compressed air: 6 atm
PROMX 1200
FEATURES:
- Up to 1200 kg/h
- Max. 4 components
- Easy cleaning
- Integrated conveying
- Automatic adaptation to bulk density
- Emptying function
- including mounting frame
- Manual operation
DESCRIPTION:
Gravimetric batch dosing device for plastic granulate, additives and regrinds. Up to 4 components are successively dosed into the weighing hopper via dosing sliders. The device has an integrated conveying system.
TECHNICAL SPECIFICATIONS:
Design: Stainless steel
Dosing: Dosing slider
Batch size: max. 15kg
Material storage: D370 – 16 Liter, D480 – 65 Liter, D630 – 135 Liter
Weighing bin: 75 Liter
Mixing container: 90 Liter
Control system: LCD 8-rows
Connection: 380-480 VAC / 50-60 Hz
Compressed air: 6 atm
